Tab 3-4 Crankshaft and main bearings

Location

code

Key Item Measured di-

rection

Nominal di-

mension (usu-

al, new) [mm]

Maximum

clearance di-

mension (be-

cause of wear)

[mm]

1132

Main bearing No. 1

001 Bearing clearance Vertical +0.4 to +0.7 0.9

1132

Main bearing No. 2 to n

002 Bearing clearance Vertical +0.3 to +0.6 0.8

NOTE: All main bearing clearances are only applicable when the tie rod studs are tight.

X72DF

AA00-0000-00AAA-034C-A

Maintenance Manual Clearances
