Tab 3-11 Supply unit - drive wheels
Location
code
Key Item Measured di-
rection
Nominal di-
mension (usu-
al, new) [mm]
Nominal di-
mension (usu-
al, new) [mm]
4104 Intermediate wheel
002
Bearing clearance Vertical
*0.121 to 0.210 0.300
003 Axial clearance Total 0.60 to 1.10
1.50
004 Tooth backlash
0.24 to 0.40 0.43
005 Tooth backlash 0.33 to 0.53
0.56
006 Tooth backlash 0.16 to 0.30 0.34
NOTE: The backlash must be measured longitudinally along the tooth crown.
NOTE: *This clearance can only be measured when the intermediate wheel is disassembled.
X72DF
AA00-0000-00AAA-034C-A
Maintenance Manual Clearances
Winterthur Gas & Diesel Ltd.
- 75 - Issue 002 2020-10
