WinGD X62DF User Manual

Tab 3-16 Torque values - standard screws
Standard thread - Grade 8.8 Fine thread - Grade 8.8 Torque value [Nm]
M3 M3 x 0.35 0.9
M4 M4 x 0.5 2.1
M5 M5 x 0.5 4.2
M6 M6 x 0.75 7.2
M8 M8 x 1 18
M10 M10 x 1.25 35
M12 M12 x 1.25 60
M14 M14 x 1.5 94
M16 M16 x 1.5 145
M18 M18 x 1.5 200
M20 M20 x 1.5 280
M22 M22 x 1.5 380
M24 M24 x 2 490
M27 M27 x 2 720
M30 M30 x 2 980
M33 M33 x 2 1300
M36 M36 x 3 1700
M39 M39 x 3 2200
M42 M42 x 3 2700
M45 M45 x 3 3400
M48 M48 x 3 4100
M52 M52 x 3 5300
M56 M56 x 4 6600
M60 M60 x 4 8100
X72DF
AA00-0000-00AAA-034A-A
Maintenance Manual Torque values - standard screws
Winterthur Gas & Diesel Ltd.
- 83 - Issue 002 2020-10
