Xerox Phaser 3600 Service Manual

3-8 Phaser 3600 Printer Service Manual
Error Messages
Sensor
Status (cont)
T2 PSize2
Sensor
The first value lists normal display
before touching the sensor, and the
second value lists normal display
after touching the sensor.
T2 Psize2 Sen
[Low] [High]
T3 PSize0
Sen
s
or
The first value lists normal display
before touching the sensor, and the
second value lists normal display
after touching the sensor.
T3 Psize0 Sen
[Low] [High]
T3 PSize1
Sen
s
or
The first value lists normal display
before touching the sensor, and the
second value lists normal display
after touching the sensor.
T3 Psize1 Sen
[Low] [High]
T3 PSize2
Sens
or
The first value lists normal display
before touching the sensor, and the
second value lists normal display
after touching the sensor.
T3 Psize2 Sen
[Low] [High]
T4 PSize0
Sen
s
or
The first value lists normal display
before touching the sensor, and the
second value lists normal display
after touching the sensor.
T4 Psize0 Sen
[Low] [High]
T4 PSize1
Sen
s
or
The first value lists normal display
before touching the sensor, and the
second value lists normal display
after touching the sensor.
T4 Psize1 Sen
[Low] [High]
T4 PSize2
Sen
s
or
The first value lists normal display
before touching the sensor, and the
second value lists normal display
after touching the sensor.
T4 Psize2 Sen
[Low] [High]
DPX Detect
Sen
s
or
The first value lists normal display
before touching the sensor, and the
second value lists normal display
after touching the sensor.
DPX Detect Sen
[Low] [High]
Motors
(T
est
2)
Main Mtr
Fwd
The motor will run on the forward
direction or stop.
Main Mtr Fwd
[On] [Off]
Main Mtr
Slow
T
he motor will run on the forward
direction in half speed mode.
Main Mtr Slow
[On] [Off]
Dev Mtr Nor The motor will run on the forward
di
rection in normal speed.
Dev Mtr Nor
[On] [Off]
Dev Mtr
Slow
T
he motor will run on the forward
direction in half speed.
Dev Mtr Slow
[On] [Off]
Duplex Mtr
Fwd
T
he motor will run on the forward
direction.
Duplex Mtr Fwd
[On] [Off]
T2 Feed
Mot
or
The motor will run on the forward
direction or stop.
T2 Feed Motor
[On] [Off]
Diagnostic Menu Map Options
Main
Menu Sub Menu Description/Function Control Panel
Display

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
