Phaser 4600/4620/4622 Printer Service Manual
SCP 7
Revised
1 Service Call Procedures
SCP 7 Configurations and Options
Configurations and Options
Refer to Table 1 for basic configurations and options. This service manual covers all configura-
tions. Within this manual ignore any references to options that are not installed.
Table 1 Phaser 4600/4620/4622 Configurations
Features 4600N 4600DN 4600DT 4620DN 4620DT
Processor Speed 700 MHz 700 MHz 700 MHz 700 MHz 700 MHz
Memory* 256 MB 256 MB 256 MB 256 MB 256 MB
Print Speed 55 ppm, Letter
52 ppm A4
55 ppm, Letter
52 ppm, A4
55 ppm, Letter
52 ppm, A4
65 ppm, Letter
62 ppm, A4
65 ppm, Letter
62 ppm, A4
PS3 Fonts (136) Standard Standard Standard Standard Standard
PCL6 Fonts (80 Scalable, 9 Bitmap) Standard Standard Standard Standard Standard
USB 2.0 Standard Standard Standard Standard Standard
Ethernet Interface 10/100 Base-TX 10/100 Base-TX 10/100 Base-TX 10/100 Base-TX 10/100 Base-TX
Tray 1 (100 sheet) Standard Standard Standard Standard Standard
Tray 2 (520 sheet) Standard Standard Standard Standard Standard
Tray 3 (520 sheet) Optional Standard Standard Optional Standard
Tray 4 (520 sheet) Optional Optional Optional Optional Optional
Tray 5 (2000 / 520-sheet) Optional Optional Optional Optional Optional
Tray 6 (520-sheet) Optional Optional Optional Optional Optional
Duplex Not available Standard Standard Standard Standard
Mailbox (4-bin) Optional Optional Optional Optional Optional
Finisher Optional Optional Optional Optional Optional
Hard Disk Drive Optional Optional Optional Optional Optional
Printer Stand Optional Optional Optional Optional Optional
Wireless LAN Optional Optional Optional Optional Optional
Printer Resolution 600 x 600 dpi
1200 Class
600 x 600 dpi
1200 Class
600 x 600 dpi
1200 Class
600 x 600 dpi
1200 Class
600 x 600 dpi
1200 Class
* All configurations have one memory slot supporting a 512 MB DDR2 DIMM, to a maximum 768 MB total.
