Xerox Phaser 4600 Service Manual

04/2016
6-28
Phaser 4600/4620/4622 Printer Service Manual
dC131, dC132
Revised
6 General Procedures and Information
dC132 NVM Reset
Purpose
To reset NVRAM to factory defaults.
1. Enter diagnostics, refer to GP 1.
2. Select Printer Routines, the DC132 NVRAM Initialization.
3. Confirm, Yes, to reset NVRAM to factory defaults.
10-105 Run Tempera-
ture Offset
Target temperature during
run mode.
0 ~ 15 (3 steps / 5
degree intervals)
5
10-115 101-185 mm
Temperature Off-
set
Offset temperature required on
thermistor B for paper width.
0 ~ 15 (4 steps / 5
degree intervals)
5
10-120 186-216 mm
Temperature Off-
set
Offset temperature required on
thermistor B for paper width.
0 ~ 15 (4 steps / 5
degree intervals)
5
10-125 60gms Tempera-
ture Offset
Media weight offset for heat roll
temperature.
0 ~ 15 (4 steps / 5
degree intervals)
5
10-130 90gms Tempera-
ture Offset
Media weight offset for heat roll
temperature.
0 ~ 10 (3 steps / 5
degree intervals)
5
10-135 Bond Tempera-
ture Offset
Media weight offset for heat roll
temperature.
0 ~ 10 (3 steps / 5
degree intervals)
5
10-140 Transparency
Temperature Off-
set
Media type offset for heat roll
temperature.
0 ~ 10 (3 steps / 5
degree intervals)
5
10-145 Cardstock Tem-
perature Offset
Media weight offset for heat roll
temperature.
0 ~ 10 (3 steps / 5
degree intervals)
5
10-150 Envelope Tem-
perature Offset
Media type offset for heat roll
temperature.
0 ~ 10 (3 steps / 5
degree intervals)
5
10-155 label Tempera-
ture Offset
Media type offset for heat roll
temperature.
0 ~ 10 (3 steps / 5
degree intervals)
5
10-200 Fuser Life Page
Counter
Fuser life count since last reset.
Read only.
Current count None
10-210 Heat Roller Life
Page Counter
Heat Roller life count since last
reset. Read only.
Current count None
10-220 Pressure Roller
Life Page
Counter
Pressure Roller life count since
last reset. Read only.
Current count None
10-300 Pick-up Interval
Delay
Change the time interval for
paper pick-up.
0 ~ 100 (* 100 msec ) 0
10-310 Pick-up Interval
Delay (Special)
Change the time interval for
special media pick-up.
0 ~ 100 (* 100 msec ) 0
T
ab
le 4 NVM Chain 10
Location NVM Name NVM Description Value Default
