Phaser 4600/4620/4622 Printer Service Manual
01-100-00, 01-102-00
2 Status Indicator RAPS
Revised
01-100-00 Top Door Open RAP
01-100-00 The Top Door is not latched.
BSD-Reference: WD 1
Initial Actions
• Close the Top Door.
• Check for obstructions blocking the latch.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Reseat the Toner Cartridge and close the Top Door. The error message is displayed.
YN
Complete.
Check the Top Door interlock actuators. The interlock actuators are undamaged.
YN
Replace the Top Door, REP 28.5.
Select dC330 code 01-100. The switch is operational (open/closed).
YN
Replace the Top/Rear Door Interlock Switch, REP 1.6.
Remove the Left Cover (REP 28.3) and check P/J45 and CN9 on the MCU Board. The con-
nections are secure.
YN
Secure the connections.
Replace these components in order until the error is corrected.
1. Top Door Interlock Switch, PL 28.15 Item 2
2. MCU Board, PL 3.10 Item 3
01-102-00 Rear Door Open RAP
01-102-00 The Rear Door is not latched.
BSD-Reference: WD 1
Initial Actions
• Close the Rear Door.
• Check for obstructions or bent pins in P/J61.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Close the Rear Door. The error message is displayed.
YN
Complete.
Check the Rear Door connection P/J63. The connector is undamaged.
YN
Repair or replace the Rear Door, REP 28.6.
Select dC330 code 01-300. The connection is operational (open/closed).
YN
Repair or replace the Rear Door, REP 28.6.
Select dC330 code 01-100 and open/close the Rear Door. The Status LED on the
Control Panel is green when the door is closed, and amber when opened.
YN
Replace the Top/Rear Door Interlock Switch, REP 1.6.
Replace these components in order until the error is corrected.
1. Rear Door, PL 28.25 Item 1
2. Joint Board, PL 9.15 Item 7
3. Exit Assembly, PL 10.30 Item 25
