Phaser 4600/4620/4622 Printer Service Manual
03-305-00, 03-315-00, 03-325-00
2 Status Indicator RAPS
Revised
03-305-00 Configuration Card Not Present RAP
03-305-00 The Configuration Card is missing from its slot on the rear panel.
BSD-Reference: WD 1
Initial Actions
• Reseat the Configuration Card.
• Cycle system power.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Remove and inspect the Configuration Card. The card is undamaged.
YN
Replace the Configuration Card.
Check the configuration card holder. The holder is secure.
YN
Secure the holder to the IP Board. Install the card.
Replace these components in order until the error is corrected.
1. Configuration Card, PL 3.10 Item 6
2. IP Board, PL 3.10 Item 2
03-315-00, 03-325-00 Manufacturer ID RAP
03-315-00 The Configuration Card is invalid for this system.
03-325-00 The Configuration Card is invalid for this system.
BSD-Reference: WD 1
Initial Actions
• Reseat the Configuration Card.
• Cycle system power.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Remove and inspect the Configuration Card. The card is undamaged.
YN
Replace the Configuration Card.
Replace these components in order until the error is corrected.
1. Configuration Card, PL 3.10 Item 6
2. IP Board, PL 3.10 Item 2
