04/2016
6-31
Phaser 4600/4620/4622 Printer Service Manual
dC330
6 General Procedures and Information
Revised
Output Components
When the appropriate code is entered, the component is activated and its status appears on
the Control Panel.
Go to the appropriate table:
• Table 9 Output Codes 04 IOT Motors
• Table 10 Output Codes 06 Laser Unit
• Table 11 Output Codes 08 Feeder motors and clutches
• Table 12 Output Codes 09 Xerographics
• Table 13 Output Codes 10 Fuser drive
• Table 14 Output Codes 12 Finisher/Mailbox drive
12-860 Low Staple Sensor Low Staple Sensor High/Low
12-870 Staple Door Switch Staple Door Interlock High/Low
12-890 Diverter Home Sensor Exit Gate Sensor High/Low
12-895 Jam Cover Sensor Rear Door Sensor High/Low
12-900 Diverter Home Sensor Exit Gate Sensor High/Low
12-905 Entrance Sensor Mailbox Entrance Sensor High/Low
12-910 Bin1 Full Mailbox Tray 1 Stack Full High/Low
12-911 Bin1 Empty Mailbox Tray 1 No Paper High/Low
12-915 Rear Door Mailbox Rear Door Interlock High/Low
12-920 Bin2 Full Mailbox Tray 2 Stack Full High/Low
12-921 Bin2 Empty Mailbox Tray 2 No Paper High/Low
12-925 Upper Diverter Home Upper Diverter Home Position High/Low
12-930 Bin3 Full Mailbox Tray 3 Stack Full High/Low
12-931 Bin3 Empty Mailbox Tray 3 No Paper High/Low
12-940 Bin4 Full Mailbox Tray 4 Stack Full High/Low
12-941 Bin4 Empty Mailbox Tray 4 No Paper High/Low
12-945 Lower Diverter Home Lower Diverter Home Position High/Low
Table 9 Output Codes 04
Code Display Name Description General
04-100 Main BLDC Motor Run the Main Drive motor On/Off
04-120 Main Fan Run the SMPS Fan On/Off
04-181 K Dev motor Run the developer motor On/Off
04-191 K Dev motor ready Run the developer motor High/Low
04-200 Exit Motor Forward Fast Run the Exit Drive Assembly On/Off
04-220 Exit Motor Reverse Reverse the Exit Drive On/Off
04-230 Duplex Motor Forward Run the Duplex Drive On/Off
04-580 Feed BLDC Motor Run the Feed Drive Assembly On/Off
04-590 Feed BLDC Motor Ready Feed Drive Assembly On/Off
Table 8 Input Codes 12
Code Display Name Description General
Table 10 Output Codes 06
Code Display Name Description General
06-100 LSU Motor Run Laser Unit scan motor On/Off
06-200 LSU LD power Laser diode half power On/Off
06-300 LSU Fan Run Right Chassis Fan On/Off
06-310 Checking LSU Hsync
Table 11 Output Codes 08
Code Display Name Description General
08-810 T1 Pick-up Clutch Tray 1 Feed Clutch On/Off
08-820 T2 Pick-up Clutch Tray 2 Feed Clutch On/Off
08-830 T3 Pick-up Clutch Tray 3 Feed Clutch On/Off
08-840 T4 Pick-up Clutch Tray 4 Feed Clutch On/Off
08-850 Registration Clutch Registration Clutch On/Off
08-855 T5 Pick-up Clutch Tray 5 Feed Clutch On/Off
08-856 T6 Pick-up Clutch Tray 6 Feed Clutch On/Off
08-820 T2 Feed Motor Run Tray 2 Feed Drive Motor On/Off
08-930 T3 Feed Motor Run Tray 3 Feed Drive Motor On/Off
08-940 T4 Feed Motor Run Tray 4 Feed Drive Motor On/Off
08-950 T5 Feed Motor Run Tray 5 Feed Drive Motor On/Off
08-960 T6 Feed Motor Run Tray 6 Feed Drive Motor On/Off
Table 12 Output Codes 09
Code Display Name Description General
09-100 MHV Bias MHV bias voltage on at nor-
mal drive level.
On/Off
09-200 Dev Bias Developer bias voltage on at
normal drive level.
On/Off
09-300 THV Bias THV plus bias voltage on at
normal drive level.
On/Off
09-400 THV Bias THV negative bias voltage on
at normal drive level.
On/Off
09-500 SMPS Fan Run Run SMPS Fan On/Off
09-600 Toner dispense motor Run the toner dispense motor
in the Main Drive Assembly
On/Off
09-950 Erase lamp Toggle the Erase lamp On/Off
Table 13 Output Codes 10
Code Display Name Description General
10-100 Fuser Power On Main Raises Fuser temperature to
180 degree setpoint.
On/Off
10-110 Fuser Power On Side Raises Fuser temperature to
180 degree setpoint.
On/Off
