Phaser 4600/4620/4622 Printer Service Manual
06-100-00, 06-200-00, 07-110-00
2 Status Indicator RAPS
Revised
06-100-00, 06-200-00 LSU Error RAP
06-100-00 The Laser Unit has failed. The Laser Unit did not reach ready within a defined time.
06-200-00 LSU Hsync Error. The Laser Unit has failed.
BSD-Reference: WD 8
Initial Actions
• Cycle system power.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Perform SCP 6 Final Actions.
Select dC330 code 06-100 to test the Laser Unit. The Laser Unit is operational (on/off).
YN
Replace the Laser Unit (REP 6.1), then retest. The Laser Unit is operational.
YN
Replace the IP Board (REP 3.6).
Reassemble and perform SCP 6 Final Actions.
Reassemble and perform SCP 6 Final Actions.
07-110-00 Paper Empty at Tray 2 RAP
07-110-00 The Tray 2 No Paper indicates the Tray is empty.
BSD-Reference: WD 3
Initial Actions
1. Add media to the Tray.
2. Check the No Paper Sensor Actuator.
3. Check for obstruction of the Pick mechanism.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Tray 2 No Paper Sensor Actuator. The actuator is undamaged and motion is
good.
YN
Repair or replace the Tray 2 No Paper Sensor Actuator.
Select dC330 code 07-210 to test the sensor. The sensor signal changes (high/low).
YN
Replace the Tray 2 No Paper Sensor (PL 8.15 Item 19), then retest. The sensor signal
changes.
YN
Remove the Right Cover (REP 28.2) and reseat CN12 on the MCU Board, then
retest. The sensor signal changes.
YN
Replace the MCU Board, REP 3.4.
Reassemble and perform SCP 6 Final Actions.
Reassemble and perform SCP 6 Final Actions.
Reassemble and perform SCP 6 Final Actions.
