Xerox Phaser 6125 Service Manual

3-16 Phaser 6125/6130 Color Laser Printer Service Manual
Error Messages and Codes
Fuser Errors
010-317 Insert Fuser
010-317
Insert Fuser
Restart Printer
<IOT Fuser Detached>
Detached Fuser is detected.
page 3-62
010-351 Replace Fuser
010-351
Replace Fuser
Restart Printer
<IOT Fuser Life Over>
Fuser has reached replacement
time.
page 3-63
010-397 Fuser Error
Restart Printer
Error 010-397
Restart Printer
010-397
Code: XX
<IOT Fuser Failure>
Fuser Failure is detected.
Shows detail of error code when
pressing three keys “Down
arrow”, “Upper arrow”, and “OK”
010-397
Code: XX
01: NC circuit fail/
02: NC Detect disconnection/
03: NC Detect fail/
04: NC Comp disconnection/
05: NC Comp fail/
06: NC Temp Over/
07: STS Temp Over/
08: NC Comp Table Fail/
09: NC Overheat/
0A: STS disconnection/
0B: STS Overheat/
0C: STS Lowtemp/
0D: NC Lowtemp/
0E: Cool Timeover/
0F: Fuser Ready Time over ERR1/
10: NC Warm up Time over ERR2/
11: Fuser Ready Time over ERR2/
12: Relay Off STS H/
13: Relay Off NC H/
14: Relay Other/
15: Fuser Machine Code ERR/
16: Fuser Ready Time over ERR3
page 3-64
Fuser Life
Replace Soon
<IOT Fuser Life Pre Warning>
Fuser is going to reach
replacement time.
page 3-63
Error Message and Chain Link Code Display (continued)
Chain Link
Code
Control Panel
Message Error Contents
Go to
Page
Scroll
Scroll
Scroll
Scroll

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
