Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 3-15
Error Messages and Codes
Low Density
Magenta Cartridge
<IOT M Toner Low Density>
Detects low density of magenta.
page 3-54
Low Density
Cyan Cartridge
<IOT C Toner Low Density>
Detects low density of cyan.
page 3-54
Low Density
Black Cartridge
<IOT K Toner Low Density>
Detects low density of black.
page 3-54
Replace
Imaging Unit
<IOT CRUM ID Error>
CRUM ID error of Imaging Unit is
detected.
page 3-71
Transfer Life
Replace Soon
<IOT DTB Life Pre Warning>
The Imaging Unit is going to
reach the replacement time.
page 3-52
Paper Setting Errors
Insert Output
to Manual Feed
< Paper Empty at Manual Duplex>
Waiting for side 2 to be set for
manual duplex print (Manual
Feed).
page 3-56
Insert Output
to Tray
< Paper Empty at Manual Duplex>
Waiting for side 2 to be set for
manual duplex print.
page 3-56
Load Manual Feed
XX (Paper size)
Load Manual Feed
YY (paper type)
<IOT Paper Size Mismatch>
Paper size mismatch detected in
Manual Feed Slot.
page 3-56
Load Manual Feed
XX (Paper size)
Load Manual Feed
YY (paper type)
<No suitable paper>
Paper empty is detected in
Manual Feed Slot.
page 3-57
Load Tray
XX (Paper size)
Load Tray
YY (paper type)
<IOT Paper Size Mismatch>
Paper size mismatch detected in
Tray.
page 3-59
Load Tray
XX (Paper size)
Load Tray
YY (paper type)
<No suitable paper>
Paper empty is detected in Tray.
page 3-60
Tray Empty <No paper in Ready>
The paper empty is detected.
page 3-60
Error Message and Chain Link Code Display (continued)
Chain Link
Code
Control Panel
Message Error Contents
Go to
Page
Scroll
Scroll
Scroll
Scroll

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
