Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 3-57
Error Messages and Codes
Load Manual Feed
No paper detected at Manual Feed Slot.
3 Check the print data, paper (print
media), and paper setting for the
following, and correct the incorrect
items:
■ Is the paper suitable for the print
data?
■ Does the paper setting match the
paper?
■ Is the paper setting suitable for the
print data?
Does the error still occur when
printing?
Go to step 4. Complete
4 Insert a sheet of paper that is suitable
for the print data and the paper
settings in the Manual Feed Slot.
Does the error still occur when
printing?
Replace the
MCU Board
(page 8-59) and
go to step 5.
Complete
5 Does the error still occur when
printing?
Replace the
Processor Board
(page 8-60).
Complete
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
Left Side Harness Assy (PL3.1.18)
Photo Sensor (PL3.2.13)
SSI Actuator (PL3.2.14)
MCU Board (PL8.2.13)
■ “Map 1 - Transfer Unit, Control Panel,
Imaging Unit, Dispenser, Fuser” on
page 10-8
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “Xerographic” on page 10-24
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the paper for loading and
setting
Check that the paper in use meets the
print job requirements
Does the error still occur after
reloading the paper and changing the
paper settings that the print job
requires?
Go to step 2. Complete
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
