Xerox Phaser 6125 Service Manual

3-58 Phaser 6125/6130 Color Laser Printer Service Manual
Error Messages and Codes
2 Reset the side guides.
Does the error still occur when
printing?
Go to step 3. Complete
3 Insert a sheet of paper that is suitable
for the print data and the paper
settings into the Manual Feed Slot.
Does the error still occur when
printing?
Go to step 4. Complete
4 Check the SSI Actuator for shape and
operation
Are the shape and operation of the SSI
Actuator normal?
Go to step 5. Reseat the SSI
Actuator. If
broken or
damaged,
replace the SSI
Actuator.
5 Check the Manual Feed Sensor (Photo
Sensor) for operation.
Perform the Manual Feed Sensor test:
Service Mode > Engine Diag > Sensor
Test > Manual Feed Sensor
Does the number on the screen
increase by one, when the SSI
Actuator is operated?
Replace the
MCU Board
(page 8-59).
Go to step 6.
6 Check the connectors of the Photo
Sensor (SSI No Paper Sensor) for
connection
Check the connections between the
MCU Board and Photo Sensor (SSI No
Paper Sensor).
Are P/J23 and P/J233 connected
correctly?
Go to step 8. Reconnect the
connector(s) P/
J23 and/or P/
J233 correctly,
then go to step
7.
7 Does the error still occur when
printing?
Go to step 8. Complete
8 Check the Left Side Harness Assy for
continuity
Disconnect J23 from the MCU Board.
Disconnect J233 from the Photo
Sensor.
Is each cable of J23 <=> J233
continuous?
Go to step 9. Replace the
Feeder Assy
(page 8-25) or
Left Side
Harness Assy
(page 8-26).
9 Check the power to the Photo Sensor
Disconnect J23 from the MCU Board.
Is the voltage across P23-6pin <=>
ground on the MCU Board, about +3.3
VDC?
Go to step 10. Replace the
MCU Board
(page 8-59).
10 Check the Photo Sensor for operation
Check the voltage across J23-8pin <=>
ground on the MCU Board.
Does the voltage change, when the SSI
Actuator is operated?
Replace the
MCU Board
(page 8-59).
Replace the
Feeder Assy.
(page 8-25).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
