Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 3-31
Error Messages and Codes
11 Check the paper lead edge stopping
position
Does the paper lead edge stop before
the Registration Roller and Metal
Registration Roller?
Go to step 12. The paper lead
edge stops past
the Registration
Roller and Metal
Regi Roller.
Go to step 14.
12 Check the paper transfer path between
the Feed Roller Assembly and
Registration Roller.
Are there any obstacles on the paper
transfer path?
Remove the
obstacles from
the paper
transfer path.
Go to step 13.
13 Check the Regi In Actuator for shape
and operation.
Are the shape and operation of the
Regi In Actuator normal?
Go to step 14. Reseat the Regi
In Actuator. If
broken or
deformed,
replace the
Feeder
Assembly
(page 8-25).
14 Check the Regi Roll Actuator for shape
and operation.
Are the shape and operation of the
Regi Roll Actuator normal?
Go to step 15. Reseat the Regi
Roll Actuator. If
broken or
deformed,
replace the
Feeder
Assembly
(page 8-25).
15 Perform the Regi. Sensor test: Service
Mode > Engine Diag > Sensor Test >
Regi Sensor.
Does the number on the screen
increase by one, when the Regi In
Actuator is operated?
Replace the
MCU Board
(page 8-59).
Go to step 22.
16 Check the connections between the
MCU Board and Main Drive Assembly
(Main Motor).
Are P/J21 and P/J211 connected
correctly?
Go to step 17. Reconnect the
connector(s) P/
J21 and/or P/
J211 correctly.
17 Check the power to the Main Drive
Assembly
Disconnect J21 from the MCU Board.
Are the voltages across J21-2/J21-4
<=> ground on the MCU Board, about
+24 VDC when the Front Cover
interlock switch is pushed?
Replace the
Main Drive
Assembly
(page 8-52).
Replace the
MCU Board
(page 8-59).
18 Check the connections between the
MCU Board and Feed Solenoid.
Are P/J23 and P/J231 connected
correctly?
Go to step 19. Reconnect the
connector(s) P/
J23 and/or P/
J231 correctly.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
