Xerox Phaser 6125 Service Manual

3-30 Phaser 6125/6130 Color Laser Printer Service Manual
Error Messages and Codes
4 Check the Main Motor (Main Drive
Assembly) for operation
Perform the Main Motor (FULL2) test
(page 4-27): Service Mode > Engine
Diag > Motor Test > Main Motor
(FULL2). During this check, defeat the
Front Cover interlock switch.
Does the Main Motor (Main Drive
Assembly) operate properly?
Go to step 5. Go to step 16.
5 Check the Feed Drive Assembly for
operation
Perform the Regi Clutch test
(page 4-33): Service Mode > Engine
Diag > Motor Test > Regi Clutch.
During this check, defeat the Front
Cover interlock switch.
Do the Registration and Metal
Registration Rollers rotate properly?
Go to step 6. Go to step 26.
6 Check the paper feeding position
Is the paper not fed from the Tray?
Go to step 7. Go to step 11.
7 Check after resetting the Side Guides
and End Guide on the Tray.
Reset the Side Guides and End Guide,
and reseat the Tray in the printer
correctly.
Does the error still occur when
printing?
Go to step 8. Complete
8 Check the Separator Roller Assembly
on the Tray for shape and rotation
Pull the Tray out from the printer.
Is the Separator Roller Assembly not
contaminated and/or damaged, and
rotated smoothly?
Go to step 9. Replace the
Separator Roller
Assembly
(page 8-7).
9 Check the Feed Roller Assembly for
shape and rotation
Pull the Tray out of the printer.
Is the Feed Roller Assembly free of
contamination and/or undamaged, and
does it rotate smoothly?
Go to step 10. Replace the
Feed Roller
Assembly
(page 8-30).
10 Check the Feed Solenoid for operation
Perform the Tray Feed Solenoid (Auto)
test (page 4-34): Service Mode >
Engine Diag > Motor Test > Tray Feed
Solenoid (Auto).
During this check, defeat the Front
Cover interlock switch.
Does the Feed Solenoid operate
properly?
Replace the
Paper Tray
(CASSETTE
ASSY 250).
Go to step 18.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
