Xerox Phaser 6125 Service Manual

3-38 Phaser 6125/6130 Color Laser Printer Service Manual
Error Messages and Codes
6 Check the Front Cover for latching
Open and close the Front Cover, and
then latch correctly.
Does the error still occur when
printing?
Go to step 7. Complete
7 Check the paper lead edge stopping
position
Does the paper lead edge stop before
the Registration Roller and Metal Regi
Roller?
Go to step 8. The paper lead
edge stops past
the Registration
Roller and Metal
Regi Roller.
Go to step 13.
8 Check after resetting the guide sides of
the Manual Feed Slot
Reset the side guides.
Does the error still occur when
printing?
Go to step 9. Complete
9 Check the paper transfer path between
the Manual Feed Slot and Regi.Sensor
Are there any obstacles on the paper
transfer path?
Remove the
obstacles or
stain from the
paper transfer
path, then go to
step 10.
Go to step 11.
10 Does the error still occur when
printing?
Go to step 11. Complete
11 Check the SSI Actuator for shape and
operation
Are the shape and operation of the SSI
Actuator normal?
Go to step 12. Reseat the SSI
Actuator. If
broken or
damaged,
replace the SSI
Actuator.
12 Check the Manual Feed Sensor (Photo
Sensor) for operation
Perform the Manual Feed Sensor test:
Service Mode > Engine Diag > Sensor
Test > Manual Feed Sensor
Does the number on the screen
increase by one, when the actuator
(Actuator SSI) is operated?
Go to step 13. Go to step 16.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
