Phaser 6125/6130 Color Laser Printer Service Manual 4-11
General Troubleshooting
K Mode Sensor K Mode Sensor
■ OFF
■ L - 0
■ H - 0
Tests the sensor for K Mode only
operation.
Manual Feed
Sensor
Manual Feed Sensor
■ OFF
■ L - 0
■ H - 0
Tests Manual Feed No Paper Sensor.
Tray No Paper Tray No Paper
■ OFF
■ L - 0
■ H - 0
Tests Tray No Paper Sensor.
Motor Test Tests the Motors of the printer.
Main Motor
(Full2)
Main Motor FULL2 Tests the Main Motor.
Main Motor
(Full1)
Main Motor FULL1
Main Motor
(Half)
Main Motor HALF
Sub Motor
(Full2)
Sub Motor FULL2 Tests the Sub Motor.
Sub Motor
(Full1)
Sub Motor FULL1
Sub Motor
(Half)
Sub Motor HALF
K Mode
Solenoid
K Mode Solenoid Tests the K Mode Solenoid.
Tray Feed
Solenoid (Half)
Tray Feed Solenoid
(Half)
Tests the Tray Feed Solenoid.
Tray Feed
Solenoid (Init)
Tray Feed Solenoid (Init) Tests the Feed Solenoid.
Fan (High) Fan (HIGH) Tests the printer Fan.
Fan (Low) Fan (LOW)
Yellow Toner
Motor
Yellow Toner Motor Tests the yellow Toner Motor.
Magenta Toner
Motor
Magenta Toner Motor Tests the magenta Toner Motor.
Cyan Toner
Motor
Cyan Toner Motor Tests the cyan Toner Motor.
Black Toner
Motor
Black Toner Motor Tests the black Toner Motor.
Regi Clutch Regi Clutch Tests the Registration Clutch.
Tray Feed
Solenoid (Auto)
Tray Feed Solenoid
(Auto)
Tests the Feed Solenoid.
Test Control Panel Display Test Description

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
