4-12 Phaser 6125/6130 Color Laser Printer Service Manual
General Troubleshooting
Drum Erase
Lamp K
Drum Erase Lamp K Tests the black Erase Lamp.
Drum Erase
Lamp YMC
Drum Erase Lamp YMC Tests the yellow, magenta, and cyan
Erase Lamps.
NVM Settings Edits, saves, loads, and prints NVRAM information.
Edit NVM Edit NVM
■ Ad0000=00000000*
■ Please wait
<Press the Left or Right
button to move the
cursor>
<Press the Up or Down
button to change the
value at the cursor>
<Press the Set button to
save the value in Engine
NVM>
<Press the Cancel button
to move one level up the
menu>
Displays the current NVRAM value.
Use this function to edit NVRAM
information.
Save NVM to
ESS
Save NVM
■ SaveNVM MCU -> ESS
OK?
■ Saved
■ Please wait
<Press the Set button to
save the value in the
Controller NVM>
<Press the Cancel button
to move one level up the
menu>
Saves the NVRAM information of the
Engine in the Controller. NVRAM
addresses to be saved are as follows:
1000-10FF, Total: 256Byte
Note: Information saved in the
Controller NVM can be initialized using
Clear All NVM.
Load NVM from
ESS
Load NVM
■ LoadNVM MCU -> ESS
OK?
■ Processing
■ Loaded
■ Please wait
<Press the Set button to
load the value saved in
the Controller NVM to the
Engine>
<Press the Cancel button
to move one level up the
menu>
Loads NVRAM information of the
Engine saved in the Controller into the
Engine.
1000-10FF / 1100-11FF / 1200-12FF
Note: Information saved in the
Controller NVM can be initialized using
Clear All NVM.
Test Control Panel Display Test Description

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
