Xerox Phaser 6125

4-18 Phaser 6125/6130 Color Laser Printer Service Manual
General Troubleshooting
Fast Scan 2
KtoM
Fast Scan 2 KtoM
■ -1 *
■ :
■ 2 *
Sets the registration in the paper
feeding direction for Manual Feed and
Tray. Adjusts by one-quarter pixel per
unit.
Fast Scan 2
KtoY
Fast Scan 2 KtoY
■ -1 *
■ :
■ 2 *
Fast Scan 2
KtoC
Fast Scan 2 KtoC
■ -1 *
■ :
■ 2 *
Life Y Toner Life Y Toner
■ 0
Reads life counter of the yellow toner.
Life M Toner Life M Toner
■ 0
Reads life counter of the magenta
toner.
Life C Toner Life C Toner
■ 0
Reads life counter of the cyan toner.
Life K Toner Life K Toner
■ 0
Reads life counter of the black toner.
Life Fuser
Sheet
Life Fuser
■ 0
Reads sheet count of the Fuser.
Life Printer
Sheet
Life Printer
■ 0
Reads sheet count of the Printer.
Life DTB Waste Life DTB Waste
■ 0
Reads life counter of the Belt Waste
Count.
Life Y
Waste Toner
Life YWaste Toner
■ 0
Reads life counter of the yellow Waste
Toner.
Life M
Waste Toner
Life MWaste Toner
■ 0
Reads life counter of the magenta
Waste Toner.
Life C
Waste Toner
Life CWaste Toner
■ 0
Reads life counter of the cyan Waste
Toner.
Life K
Waste Toner
Life KWaste Toner
■ 0
Reads life counter of the black Waste
Toner.
Life IU Y Time Life IU Y Time
■ 0
Reads dispense time of the yellow
Developer.
Life IU M Time Life IU M Time
■ 0
Reads dispense time of the magenta
Developer.
Life IU C Time Life IU C Time
■ 0
Reads dispense time of the cyan
Developer.
Life IU K Time Life IU K Time
■ 0
Reads dispense time of the black
Developer.
Test Control Panel Display Test Description
