General Troubleshooting
Gradation ESS Gradation ESS
■ Ready
■ Processing
Prints a pattern in which the density of
each cyan, magenta, yellow, or black is
varied from 0-100%.
Toner Pallet
Check
Toner Pallet Check Prints a pattern of 100% density of
each color.
Contamination
Check
Contamination Check Prints a scale pattern for each color
(sheets 1-4) and the Pitch Chart, a
repeating defects page (sheet 5).
Parameter Reads/writes the parameter values, errors, and life counter values
stored in the printer.
Slow Scan KtoP Slow Scan KtoP
■ -128 *
■ :
■ 127 *
Adjusts the registration in the scanning
direction.
Slow Scan
600M
Slow Scan 600M
■ -30 *
■ :
■ 30 *
Slow Scan
600Y
Slow Scan 600Y
■ -30 *
■ :
■ 30 *
Slow Scan
600C
Slow Scan 600C
■ -30 *
■ :
■ 30 *
Fast Scan KtoM Fast Scan KtoM
■ -30 *
■ :
■ 30 *
Sets the registration in the paper
feeding direction for Manual Feed and
Tray. Adjusts by one pixel per unit.
Fast Scan KtoY Fast Scan KtoY
■ -30 *
■ :
■ 30 *
Fast Scan KtoC Fast Scan KtoC
■ -30 *
■ :
■ 30 *
Fast Scan
M-feed
Fast Scan M-feed
■ -30 *
■ :
■ 30 *
Fast Scan
Tray
Fast Scan Tray
■ -30 *
■ :
■ 30 *
Test Control Panel Display Test Description
