4-16 Phaser 6125/6130 Color Laser Printer Service Manual
General Troubleshooting
Clear All NVM Clear All NVM
■ OK?
■ Processing
■ Initialized
<Press the Cancel button
to move one level up the
menu>
<Press the Set button to
run the test>
Clears all NVRAM of the Controller.
Clear Job
History
Clear JobHistory
■ OK?
■ Processing
■ Initialized
<Press the Cancel button
to move one level up the
menu>
<Press the Set button to
run the test>
Deletes the job history data.
Note: Job History can also be
initialized by Clear All NVM.
Clear
Auditron PV
Not used in this printer.
Test Print Provides various test prints to be used for troubleshooting the
printer.
No Image IOT No Image IOT
■ Ready
■ Processing
Prints a blank page.
Pattern IOT Pattern IOT
■ Ready
■ Processing
Prints the printer built-in Test Pattern
600 DPI. This test checks the print
function of the printer.
Grid 2 ESS Grid 2 ESS
■ Ready
■ Processing
Prints the Controller built-in grid
pattern. This test checks the print
function of the printer.
Cyan 20% ESS Cyan 20% ESS
■ Ready
■ Processing
Prints 20% density paint pattern of
cyan on the whole page.
Magenta 20%
ESS
Magenta 20% ESS
■ Ready
■ Processing
Prints 20% density paint pattern of
magenta on the whole page.
Yellow 20%
ESS
Yellow 20% ESS
■ Ready
■ Processing
Prints 20% density paint pattern of
yellow on the whole page.
Black 20% ESS Black 20% ESS
■ Ready
■ Processing
Prints 20% density paint pattern of
black on the whole page.
CMY 20% ESS CMY 20% ESS
■ Ready
■ Processing
Prints 20% density paint pattern of
cyan, magenta, and black combined on
the whole page.
Test Control Panel Display Test Description

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
