Xerox Phaser 6125

Phaser 6125/6130 Color Laser Printer Service Manual 10-3
Plug/Jack and Wiring Diagrams
24 4 J-158 Connects MCU Board and Feeder Drive Assy (Color
Mode Switching Solenoid)
26 4 J-158 Connects MCU Board and Ksnr Regcl Harness Assy
28 4 J-158 Connects MCU Board and L Side Harness Assy
29 3 C-139 Connects Image Processor Board and B Harness
Assy
29 4 I-158 Connects MCU Board and Side Switch Harness
Assy
31 4 H-157 Connects MCU Board and Toner CRUM Harness
Assy
40 3 C-136 Connects LVPS Board and Image Processor Power
Harness Assy
40 4 I-156 Connects MCU Board and Laser Unit RE Harness
Assy
41 4 I-156 Connects MCU Board and Laser Unit Video Harness
Assy
42 4 J-157 Connects MCU Board and Imaging Unit XPRO
Harness Assy
44 3 G-136 Connects LVPS Board and Interlock Switch
47 3 F-136 Connects LVPS Board and Fuser Harness Assy
48 3 G-137 Connects LVPS Board and Power Switch Harness
Assy
101 3 D-138 Connects Image Processor Board and Image
Processor Harness Assy
101 4 I-157 Not Connect (Debug only)
111 3 E-138 Connects Image Processor Board and Image
Processor Video Harness Assy
141 1 G-107 Connects Erase LED Assy and LVPS Harness Assy
144 4 G-151 Connects PWBA EEPROM and Imaging Unit XPRO
Harness Assy
161 4 F-153 Connects PWBA HVPS and HVPS Harness Assy
171 1 H-106 Connects FUSER and Fuser Harness Assy
181 4 C-152 Connects Dispenser Assy (Y-Dispenser Motor Assy)
and TNR Motor Harness Assy
182 4 C-151 Connects Dispenser Assy (M-Dispenser Motor
Assy) and TNR Motor Harness Assy
191 4 C-151 Connects Dispenser Assy (C-Dispenser Motor Assy)
and TNR Motor Harness Assy
192 4 C-150 Connects Dispenser Assy (K-Dispenser Motor Assy)
and TNR Motor Harness Assy
Print Engine Plug/Jack Designators (continued)
P/J Map Coordinates Remarks
