Xerox Phaser 6125

10-4 Phaser 6125/6130 Color Laser Printer Service Manual
Plug/Jack and Wiring Diagrams
201 3 H-140 Connects NV Feeder Assy (HUM Sensor) and HUM
Harness Assy
211 3 J-138 Connects Main Drive Assy (Main Motor) and Main
Motor Harness Assy
220 1 E-106 Connects Control Panel Assy and A-OP Harness
Assy
221 3 H-138 Connects Sub Drive Assy (Sub Motor) and Sub
Motor Harness Assy
231 2 C-125 Connects NV Feeder Assy (Feed Solenoid) and L
Side Harness Assy
232 2 F-125 Connects NV Feeder Assy (REGI SensorI) and L
Side Harness Assy
233 2 G-125 Connects NV Feeder Assy (SSI No Paper Sensor)
and L Side Harness Assy
234 2 F-124 Connects NV Feeder Assy (Tray No Paper Sensor)
and L Side Harness Assy
261 3 H-139 Connects Feeder Drive Assy (Color Mode Switching
Sensor) and Ksnr Regcl Harness Assy
262 3 I-139 Connects Drive Clutch Assy and Ksnr Regcl Harness
Assy
281 1 C-108 Connects Transfer Belt (ADC SNR2 Harness Assy)
and L Side Harness Assy
291 1 H-107 Connects Dispenser Assy (Toner Access Door
Switch) and Side Switch Harness Assy
311 1 H-110 Connects Dispenser Assy (Connector CRUM Y) and
Toner CRUM Harness Assy
312 1 H-109 Connects Dispenser Assy (Connector CRUM M) and
Toner CRUM Harness Assy
313 1 H-108 Connects Dispenser Assy (Connector CRUM C) and
Toner CRUM Harness Assy
314 1 H-108 Connects Dispenser Assy (Connector CRUM K) and
Toner CRUM Harness Assy
401 3 C-139 Connects Image Processor Board and Image
Processor Power Harness Assy
411 2 D-122 Connects ROS ASSY and Laser Unit RE Harness
Assy
412 2 D-123 Connects ROS ASSY and Laser Unit Video Harness
Assy
422 4 G-150 Connects Imaging Unit (Eeprom Imaging Unit) and
Imaging Unit XPRO Harness Assy
482 3 G-140 Connects GFI Breaker and Power Switch Harness
Assy
Print Engine Plug/Jack Designators (continued)
P/J Map Coordinates Remarks
