Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 10-5
Plug/Jack and Wiring Diagrams
483 3 G-140 Connects GFI Breaker and Power Switch Harness
Assy
484 3 G-141 Connects GFI Breaker and GFI Ground Harness Assy
501 3 D-136 Connects LVPS Board and LVPS Harness Assy
502 3 C-136 Connects LVPS Board and 24V Harness Assy
503 3 C-136 Connects LVPS Board and FAN
504 3 D-136 Connects LVPS Board and RL Test Harness Assy
2811 1 D-107 Connects ADC Sensor and ADC SNR2 Harness Assy
(Transfer Belt)
5041 1 I-107 No Connection (Used in production process only)
2200/
2900
1 H-111 Connects A-OP Harness Assy and B Harness Assy
Print Engine Plug/Jack Designators (continued)
P/J Map Coordinates Remarks

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
