Xerox Phaser 8400 Service Manual

4-14 Phaser 8400/8500/8550 Color Printer
3 Peak Power Time
(sec)
0.05 to 0.19 Reports time after solenoid
power on that the peak power
occurred.
4 Initial Average
Power (watts)
17 to 26 Reports the average power
following power on.
Tray 2, Tray 3, Tray 4, Pick Clutch
Gathers data on the performance of the pick clutch coil for Trays 2 through 4. The same type of
clutch is used for each tray.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
0 Peak Power (watts) 2.5 to 5.5 3.0 to 6.0 Reports the profile max power
value.
1 Average Power
(watts)
2.5 to 5.5 2.0 to 6.5 Reports the average power
during the constant portion of
the profile.
Strip Solenoid
Gathers data on the performance of the stripper solenoid coil and plunger.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
0 Peak Power (watts) 8.0 to 15 22 to 27 Reports the profile max power
value.
1 Average Power
(watts)
8.0 to 15 20.0 to 30.0 Reports the average power
during the constant portion of
the profile.
Tray 1 Pick Solenoid
Gathers data on the performance of the Tray 1 pick solenoid coil and flapper.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
