Xerox Phaser 8400 Service Manual

General Troubleshooting 4-13
Check / Activators Menu
Head Maintenance Clutch
Gathers data on the performance of the head maintenance clutch coil.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
0 Peak Power (watts) 3.0 to 5.9 3.2 to 6.3 Reports the profile max power
value.
1 Average Power
(watts)
2.8 2.2 to 3.5 Reports the average power
during the constant portion of the
profile.
Deskew Clutch
Gathers data on the performance of the deskew clutch coil.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
0 Peak Power (watts) 2.5 to 5.3 3.0 to 5.8 Reports the profile max power.
1 Average Power
(watts)
2.2 to 5.3 1.5 to 3.0 Reports the average power
during the constant portion of the
profile.
Tray 1 Pick Solenoid
Gathers data on the performance of the Tray 1 pick solenoid coil and flapper.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
0 Peak Power (watts) 20.0 to 30 20 to 25 Reports the profile max power
value.
1 Average Power
(watts)
20.0 to 30 19 to 26 Reports the average power
during the constant portion of
the profile.
2 Min Power (watts) -5.0 to -0.4 Reports the min power
following power off.
