8-2 Phaser 8400/8500/8550 Color Printer
Overview
This section contains the removal and replacement procedures for selected parts of the
printer according to the Field Replaceable Units (Service Parts) Parts List. In general,
replacement procedures are not given because re-installing a part is usually simply a
reversal of the disassembly. Replacement procedures are included where this is not
the case and special steps are required. Replacement notes are included when they can
help ease or shorten the reassembly process.
Standard Orientation of the Printer
When needed the orientation of the printer is called out in the procedure for locating
printer parts. Refer to the printer orientation graphic for locating the right, left, front
and back sides of the printer.
s8500-002
Left
Right
Back
Front
