6-2 Phaser 8400/8500/8550 Color Printer
Adjustments
Wiper Alignment Procedure
1. Remove the printer covers using the procedures that begin on page 8-4.
2. Remove the left head maintenance drive gear (see the following figure) by
removing the e-clip from the drive shaft.
Left Idler Gear
Left Drive Gear
s8500-059
