Xerox Phaser 8400

Wiring Diagrams 10-5
Right-Side Wiring Diagram (Continued)
The arrows indicate which connectors you should look at for the Pest codes. The Pest
codes are displayed on the Control Panel.
13387.4x
37027.4x X-Motor Ribbon Cable (Routed in
Middle of Channel)
Routes to Top of Channel
J800 Dead
Power
J4AC 37006.4x
J400 37027.4x
Signal Cable
(Routed on
Bottom of Channel)
s8500-126
