Xerox Phaser 8400 Service Manual

4-42 Phaser 8400/8500/8550 Color Printer
Check Drum Menu
Y-axis Encoder
Uses the sine and cosine sum data to determine the characteristics of the encoder disk and
encoder sensors.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
0 Sin Sum Data Offset
(sin sum units)
150000 to
800000
-68000 to
160000
Reports average of the max and
min Sin Sum average amplitude
values.
1 Sin Sum Data
Amplitude (sin sum
units)
-11000 to
350000
-68000 to
160000
Reports difference between the
max and min Sin Sum average
amplitude values.
2 Amplitude Ripple
(Sun Sum units)
25 to 75 2.0 to 12 Reports the ripple in the Sin Sum
amplitude values. Excludes the
neighborhood of the Home notch
(a distance of +/- 50 samples
from the Home notch min
location.
3 Max Position Ripple
(mpts)
-140000
to 275000
24000 to
52000
Reports the max variation in the
reported delta position between
samples over the revolution.
4 Sin max delta
position
-.3 to 5 -.3 to 5 Reports the max value of the
diference between the rotation
position of any adjacent sin sum
peaks
5 Home Notch Depth
Ratio (none)
0 to 13 68 to 80 Reports the ratio between the
notch bottom amplitude and the
max amplitude value as reflected
in the Sin Sum data.
6 Home Notch Width
(sec)
50 to 90 720 to
960
Reports the width of the Home
notch at 99% full depth as
reflected in the Sin Sum data.
7 Home Notch
Symmetry (none)
250 to
550
35 to 65 Reports the ratio of the Home
notch width sections as bisected
by a vertical from the notch min
as reflected in the Sin Sum data.
8 Cosine Sum Data
Offset (cosine sum
units)
90000 to
450000
-125000
to 200000
Reports average of the max and
min Cosine Sum average
amplitude values.
9 Cosine Sum Data
Amplitude (cosine
sum units)
300000 to
500000
300000 to
500000
Reports difference between the
max and min Cosine Sum
average amplitude values.
