2-2 Phaser 8400/8500/8550 Color Printer
Main Printer Subsystems
Printer Subsystem Overview
The printer is made up of eight major subsystems, which are described in this section:
â– Process Drive
â– Media Path Drive
â– Ink Loader
â– Printhead
â– Drum Maintenance System
â– Purge System
â– Drum Assembly and Transfix Assembly
â– Electronics Module
s8500-008
Duplex Print Path
Transfix System
Paper Preheater
(and Deskew)
Printhead
Drum
Ink Loader
Wiper Assembly
*Power Supply
*Hard Drive
*Main
Board
*Power Control
Board
Paper/Media Tray
Drum Maintenance Kit
Wave Amp
*Configuration
Card
Ink Waste Tray
*Part of the Electronics Module
