1-10 Phaser 8400/8500/8550 Color Printer
Printer Specifications
Physical Dimensions and Clearances
Print Engine Only Value
Width: 422 mm (16.6 in.)
Depth: 514 mm (20.24 in.)
Height: 368 mm (14.48 in.)
Weight: 26.8 kg (59 lb.)
Optional 525-Sheet Feeder Value
Width: 422 mm (16.6 in.)
Depth: 514 mm (20.24 in.)
Height: 132 mm (5.2 in.)
Weight: 5.4 kg (12 lb.)
Minimum Clearances Supplemental Information
Left side and rear - 102 mm (4 in.) Required for airflow.
Right side - 394 mm (15.5 in.) Required for maintenance kit and waste tray access,
and airflow.
Front - Unrestricted Required for media tray and jam access.
Top - 559 mm (22 in.) printer only Required for inkload and jam access.
Bottom - No obstruction between
mounting surface and printer
Required for airflow.
Min. install width - 711 mm (28 in.) Requires placing printer at an angle to remove waste
tray.
A. Absolute Minimum B. Recommended Minimum
4.0
6.0 6.0
28.0
4.0
4.0 15.5
35.5
Front
24.0
Note: All dimensions in inches
