Xerox Phaser 8400 Service Manual

4-32 Phaser 8400/8500/8550 Color Printer
Duplex Paper Lead Edge Times
Paper is picked and moved through either simplex or duplex paper path to determine leading
edge arrival time at each paper path sensor. R values have alternate definitions or are unused
depending on the pick tray and if simplex or duplex path was selected.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
8 Duplex Turnaround
Interval (us)
Reports the interval from the time
the engine software is
commanded to start the duplex
exit process until the Strip sensor
deactivates.
9 Duplex Pick Interval
(us)
Reports the interval from the time
the engine software is
commanded to start the duplex
pick process until the Deskew
sensor activates
10 Duplex Stage
Interval (us)
Reports the interval from the time
the engine software is
commanded to start the stage
process until the Preheat sensor
activates (part way through the
stage paper motion).
11 Duplex Transfix
Interval (us)
Reports the interval from the time
the engine software is
commanded to start the transfix
process until the Strip sensor
activates (part way through the
paper transfix motion).
12 Duplex Exit Interval
(us)
Reports the interval from the time
the engine software is
commanded to start the transfix
process until the Exit sensor
activates (part way through the
paper transfix motion).
13 Duplex Exited
Interval (us)
Reports the interval from the time
the engine software is
commanded to start the exit
process until the Exit sensor
deactivates.
