Xerox Phaser 8400 Service Manual

4-34 Phaser 8400/8500/8550 Color Printer
Duplex Paper Sensor Bounce Times
Paper is picked and moved through either the duplex paper path to determine the paper trailing
edge bounce interval at each paper path sensor. R values have alternate definitions or are
unused depending on the pick tray and if simplex or duplex path was selected.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
7 Exit Bounce Interval
(us)
Reports the interval during which
the Exit sensor bounces following
the passage of the paper trailing
edge during duplex turnaround.
8 Duplex Deskew
Bounce Interval (us)
Reports the interval during which
the Deskew sensor bounces
following the passage of the
paper trailing edge.
9 Duplex Preheat
Bounce Interval (us)
Reports the interval during which
the Preheat sensor bounces
following the passage of the
paper trailing edge.
10 Duplex Strip Bounce
Interval (us)
Reports the interval during which
the Strip sensor bounces
following the passage of the
paper trailing
11 Duplex Exit Bounce
Interval (us)
Reports the interval during which
the Exit sensor bounces following
the passage of the paper trailing
edge.
