Xerox Phaser 8400 Service Manual

General Troubleshooting 4-51
Tray 2, Tray 3, Tray 4, Lift Motor
his test turns on the specified motor and runs it at constant velocity for approximately 20
revolutions while recording drive data. The test is the same for each motor. Requesting a test for
a 525-sheet feeder that is not installed will generate an “Option Not Detected” message.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
0 Motor Peak Power
(watts)
1 to 2.5 Reports max amount of motor
power over the run interval.
1 Motor Average
Power (watts)
.25 to .55 Reports the average motor drive
power over the last half of the run
interval.
2 Brake Average
Power (watts)
.10 to .20 Reports the average motor brake
power over the stop with brake
interval.
Tray 3 and Tray 4 Pick/Feed Motor
This test turns on the specified motor and runs it at constant velocity for approximately 25
revolutions while recording drive data. The test is the same for each motor. Requesting a test for
a 525-sheet feeder that is not installed will generate an “Option Not Detected” message.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
0 Motor fe ripple
(ticks)
Reports amount of variation of
the motor following error over the
recording interval.
1 Motor fe average
(ticks)
Reports the motor following error
average value of the recording
interval.
2 Motor drive voltage
ripple (volts)
Reports amount of variation of
the motor drive voltage over the
recording interval.
3 Motor drive voltage
(volts)
Reports the motor drive voltage
average value of the recording
interval.
4 Motor drive power
ripple (watts)
Reports amount of variation of
the motor drive power over the
recording interval.
