Xerox Phaser 8400 Service Manual

4-54 Phaser 8400/8500/8550 Color Printer
2, 3,
4
3 - media length bottom
2, 3,
4
2 - Media width top
2, 3,
4
1 - media width middle
2, 3,
4
0 - Media width bottom
Temperature Status
This test scans the thermocouples and reports data on the current temperature with the goal of
providing a picture of the current temperature state of the printer. All degrees are reported in
celsius.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
0 Reservoir Temp
~127.7
o
~135.0
o
Reports the current temperature
1 Left Jetstack
~134
o
~138
o
Reports the current temperature
2 Right Jetstack
~134
o
~138
o
Reports the current temperature
3 Preheater Temp
~62
o
~70
Reports the current temperature
4 Drum Temp
~60
o
~60
o
Reports the current temperature
5 Ink Melt 1 Temp
~50
o
~50
o
Yellow (usually off)
6 Ink Melt 2 Temp
~50
o
~50
o
Cyan (usually off)
7 Ink Melt 3 Temp
~50
o
~50
o
Magenta (usually off)
Paper Path Status (Continued)
This test looks at the paper path sensors to identify if anything would prevent a page from
printing. The Control Panel will display messages indicating if anything unexpected is found for:
R0 = upper paper path; R1 = tray 1; R2 = tray 2; R3 = tray 3; and R4 = tray 4. The display is a
string of 0’s and 1’s (one digit for each sensor state) and is listed below from most significant bit to
least significant bit.
1 = an item that needs to be corrected.
0 = normal
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
