Xerox Phaser 8400 Service Manual

Parts Lists 9-7
Parts List 2.0 Imaging
No. Name/Description Qty Part Number
1
Ink Loader Assembly and Door 1 200469880 (8400)
133K25031 (8500/8550)
133K25660 (Metered PagePack
8550)
2
Printhead Assembly 1 650430300 (8400)
046K00510 (8500/8550)
3
Drum Assembly, includes Encoder 1 105115080 (8400)
020K14790 (8500/8550)
4
Belt, Y-Axis Drum 1 214498780 (8400)
023E30670 (8500/8550)
5
Printhead Wiper (for wide-style belts) 1 367053480 (8400, 8500/8550)
6
Belt, Wiper Drive (wide-style) 1 214501280 (8400, 8500/8550)
no narrow belt, use wide wiper&belt
7
Purge Pressure Pump 1 604K31120
8
Left Printhead Restraint 1 343167280
9
Right Printhead Restraint 1 343167180
10
Transfix Camshaft Assembly 1 384187480 (8400)
008K02160 (8500/8550)
11
Drum Maintenance Camshaft Assembly 1 401100380 (8400)
020K14800 (8500/8550)
12
Stripper Carriage Assembly 1 386735280 (8400)
041K06500 (8500/8550)
13
Transfix Roller 1 401102780 (8400)
022E32290 (8500/8550)
14
Y-Axis Tension Spring 1 214499680
15
Transfix Load Arm Module Assembly 1 386739380 (8400)
137E14030 (8500/8550)
16
Drum Maintenance Pivot Plate Assembly 1 367053181
17
Preheater and Deskew Assembly 1 119641980 (8400)
126K23150 (8500/8550)
18
Transfix Arm Assembly 1 401101280 (8400)
059K50010 (8500/8550)
19
X-Axis Bias Spring Hook 1 214503280
20
X-Axis Roll Adjuster Spring 1 214503180
21
Printhead X-Axis Bias Spring
1 214503080
