Xerox Phaser 8400

Parts Lists 9-9
Parts List 3.0 Paper Path
No. Name/Description Qty Part Number
1
Inner Simplex Guide 1 351111480 (8400)
032E29480 (8500/8550)
2
Lower Inner Duplex Guide 1 038K16870
3
Lower Exit Guide Assembly with Strip Flag 1 038K16880
4
Outer Duplex Paper Guide with Sensors (Safety
Interlocks)
1 351113680
5
Upper Duplex Paper Guide with Solenoid 1 351113280 (8400)
032E29490 (8500/8550)
6
Exit Roller 1 401091980
7
Take Away Roller 1 401094780
8
Duplex Roller 1 401091880
9
Separator Pad Kit 1 650429300 (8400)
604K31140 (8500/8550)
10
Pick Assembly and Retard Roller Kit 1 650429200 (8400)
604K31130 (8500/8550)
11
Main Tray (Tray 2) 1 650433200 (8400)
050E23080 (8500/8550)
12
525-Sheet Feeder and Tray 1 650433100
13
Exit Module Assembly 1 441223980 (8400)
133K25020 (8500/8550)
