Parts Lists 9-11
Parts List 4.0 Motors, Gears, Solenoids, Clutches, and Fans
No. Name/Description Qty Part Number
1
Pre-heater Lift Solenoid 1 121K44430 (8500/8550)
2
Motor, Y-Axis Drive 1 147101780
3
Pick Solenoid, Tray 1 1 119640880
4
Head Tilt Solenoid 1 121K44480 (8500/8550)
5
Gearbox, Media Drive with 2 Clutches, Solenoid 1 401098480 (8400)
807E16050 (8500/8550)
6
Tray Lift Motor Kit and Gear (plus item 10) 1 650429500
7
Paper Path Cooling fan 1 119650580 (8400)
No longer orderable (refer to
service bulletin 655).
8
Electronics Module System Fan 1 119642680 (8400)
133K25010 (8500/8550)
9
Compound Gear, Head Tilt 1 401097880
10
Tray Lift Motor Kit and Gear (plus item 6) 1 650429500
11
Electric Clutch, Wiper 1 401096180
12
X-Axis Motor Assembly 1 650429400
13
Drum Cooling Fan 1 119641780 (8400)
127E15090 (8500/8550)
14
Gearbox and Motor, Process Drive 1 401100080 (8400)
127K53240 (8500/8550)
To Next Page
