Xerox Phaser 8400 Service Manual

Parts Lists 9-13
Parts List 5.0 Circuit Boards and Cables
No. Name/Description Qty Part Number
1
Cable, Y-Axis Motor Ground 1 117E28740
2
Wiring Harness, Left Side Power Control 1 174449480 (8400)
117E28720 (8500/8550)
3
Cable, Wave Amp Signal 1 174446580 (8400)
117E28680 (8500/8550)
4
Wave Amp Assembly 1 671522380 (8400)
960K21180 (8500/8550)
5
Electronics Module (no RAM, NVRAM, or
Configuration Card)
1 119649580 (8400)
137E14020 (8500/8550)
6
Cable, Printhead Interface 1 174448580
7
Hard Drive Assembly
Hard Drive with Japanese Fonts
1
1
1
097S03172 (8400)
121K44411 (8500/8550)
097S03173 (8400)
121K44420 (8500/8550)
8
128 MB SDRAM
256 MB SDRAM
128 MB SDRAM
256 MB SDRAM
512 MB SDRAM
1 156483700 (8400)
156466300 (8400)
856000200 (8500)
856000300 (8500/8550)
856000400 (8550)
9
8-pin NVRAM 1 156476800
10
Configuration Card-B, Prog.
Configuration Card-BD, Prog.
Configuration Card-N, Prog.
Configuration Card-DP, Prog.
Configuration Card-DX, Prog.
Configuration Card-N, Prog.
Configuration Card-DN, Prog.
Configuration Card-DP, DT and DX, prog.
1
1
1
1
1
1
1
650431200 (8400)
650431300 (8400)
650431400 (8400)
650431500 (8400)
650431600 (8400)
069E00360 (8500)
069E00370 (8500)
069E00380 (8550)
11
Cable, Flex, Wave Amp Drive 1 174448680 (8400)
117E28670 (8500/8550)
12
Cable, Right Side Power Control 1 174446680
13
I/O Board 1 671529100 (8400)
960K22330 (8550/8550)
14
Cable, Combined Right (Ink Loader Data,
Preheater AC)
1 174451180 (8400)
117E28730 (8500/8550)
15
Cable, I/O Board Data 1 174447480
16
Cable, Right Umbilical 1 174448180
17
Drum Heater Relay Board 1 650431700
18
Cable, Front Door 1 174447880
