YASKAWA NX100 Instructions

8.11 All Limit Release Function
8-78
8.11 All Limit Release Function
The following limits can be released with the All Limit Release function:
• To operate the manipulator with all limits released, pay extra attention
to ensure the safety of the surrounding operation environment.
Failure to observe this caution may result in injury or damage to equipment due to the
unexpected manipulator motion exceeding its range of motion.
Limit Type Contents
Mechanical Limit Limit to check manipulator’s range of motion.
L-U Interference Limit to check L- and U-axis interference area.
Soft Limit on Each Axis Soft limit to check manipulator’s range of motion.
Cube Interference Limit to check cube interference area set by user.
All limit release function is not available if the security mode is not in the management
mode. Refer to "7 Security System" for details on the security modes.
CAUTION
NOTE

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
