11.2 Addition of Base and Station Axes
11-15
3 Modify the settings.
4 Press [ENTER] in the MOTOR
SPEC window.
After the setting, the current window moves to the window for the
next axis setting. Complete the settings for all axes in the same
manner.
When [ENTER] is pressed in the MOTOR SPEC window for the
last axis, the setting in the MOTOR SPEC window is completed
and the confirmation dialog box appears.
If {YES} is selected, the system parameter is set automatically.
Operation Explanation
Short CutMain Menu Maintenance mode
CONTROL GROUP
: EA1400N-A0
: RECT-XYZ
: HP20-A0
: NONE
: NONE
: TURN-1
: TURN-1
: NONE
R1
B1
R2
B2
R3
S1
S2
S3
Modify?
NO
YES
