YASKAWA NX100 Instructions

13.2 Power Supply Contactor Sequence Circuit Board (JANCD-NTU01-)
13-7
Fig. 3 Connection for External Axis Overrun
• Remove jumper cable installed on system input signal before connect-
ing the input signal lines.
Failure to observe this caution could lead to injury or mechanical failure.
CAUTION
NX100
CN06
-5
-6
-7
-8
+24V2
EXOT1
EXOT2
024V
Remove the jumper cable
Turn ON/OFF
at the same time
External axis overrun
Power supply contactor unit
JZRCR-NTU

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
