7-4
IM 05P02C41-01EN
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
SL
(Scaling)
Minimum value of PV
input scale
EASY
-19999 to 30000, (SL<SH),
|SH-SL|≤30000
PV
Minimum value of RSP
remote input range
EASY RSP
Minimum value of AIN2
aux. analog input scale
EASY AIN2
Minimum value of AIN4
aux. analog input scale
EASY AIN4
Note 1: For remote input with the optional suffix code /DR, setting range for RSP remote input type
is same as that for PV input type.
When the optional suffix code /U1 is specified, RSP remote input type is same as PV input
type.
Note 2: When each parameter is displayed, the terminal area (E1 to E4) is displayed on Group
display according to the suffix code and optional suffix code.
IN, UNIT, RH, and RL described above are the parameters to be used for processing
before the input ladder calculation program.
The following parameters are used for processing after the input ladder calculation
program.
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
P.UNI Control PV input unit
STD
-: No unit
C: Degree Celsius
-: No unit
- -: No unit
- - -: No unit
F: Degree Fahrenheit
MPV
P.DP
Control PV input
decimal point position
0: No decimal place
1: One decimal place
2: Two decimal places
3: Three decimal places
4: Four decimal places
P.RH
Maximum value of
control PV input range
-19999 to 30000, (P.RL<P.RH),
|P.RH-P.RL|≤30000
P.RL
Minimum value of
control PV input range
Note1: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
7.1SettingFunctionsofPVInput,RemoteInput,andAuxiliaryAnalogInput
