9-25
IM 05P02C41-01EN
Program Pattern Functions
9
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
JC Junction code STD
CONT: Switching for continuation
HOLD: Hold-on switching (the
controller holds the end-of-
segment setpoint when the
segment is completed, to perform
control).
LOC: Local-mode switching (the
controller switches to a local
setpoint when the segment is
completed).
REM: Remote-mode switching (the
controller switches to a remote
setpoint when the segment is
completed).
W.SW1 to W.SW5: Wait during
switching between segments.
W.IV1 to W.IV5: Wait within a segment
interval.
W.SL1 to W.SL5: Segment switching
(the controller switches to a
local setpoint when the segment
is completed after release.) (5
groups)
W.SR1 to W.SR5: Segment switching
(the controller switches to a
remote setpoint when the segment
is completed after release.) (5
groups)
PLK.1 to PLK.30 (PLK.99): Linked to
patterns 1 to 30 (99).
INS.: Allows a segment to be added to
theendofaspeciedsegment.
DEL.:Allowsaspeciedsegmentto
be deleted.
PROG
9.6OperationwithLinkedProgramPatterns
