YOKOGAWA UP55A User Manual

9-50
IM 05P02C41-01EN
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
WAIT
Wait ON/OFF
switch
STD
Set an I relay number of contact
input.
Set “OFF” to disable the function.
Standard terminals
DI1: 5025, DI2: 5026,
DI3: 5027
E1-terminal area
DI11: 5041, DI12: 5042,
DI13: 5043, DI14: 5044,
DI15: 5045, DI16: 5046
E2-terminal area
DI21: 5057, DI22: 5058,
DI23: 5059, DI24: 5060,
DI25: 5061, DI26: 5062
E3-terminal area
DI31: 5073, DI32: 5074,
DI33: 5075, DI34: 5076,
DI35: 5077
E4-terminal area
DI41: 5089, DI42: 5090,
DI43: 5091, DI44: 5092,
DI45: 5093, DI46: 5094
DI.SL
AL1.S
AL1 function
selection
STD
Controlagforsegmenttransition:
4261
ALM
AL2.S
AL2 function
selection
AL3.S
AL3 function
selection
OR.S
OUT relay function
selection
OR2.S
OUT2 relay function
selection
DO1.S
DOn1 function
selection
STD
Controlagforsegmenttransition:
4261
DO
DO2.S
DOn2 function
selection
DO3.S
DOn3 function
selection
DO4.S
DOn4 function
selection
DO5.S
DOn5 function
selection
n: Terminal area number (1 to 4)
9.14SynchronizedProgramPatternOperation
