PROG/HOLDSwitch(P/H)
PROG/HOLD mode can be switched using contact input. (Switch by the rising edge and
the falling edge)
Contact status Operation Remark
OFF→ON PROG –
ON→OFF HOLD –
PROG/LOCAL(LSP)Switch(P/L)
PROG/LOCAL(LSP) mode can be switched using contact input. (Switch by the rising
edge and the falling edge)
Contact status Operation Remark
OFF→ON PROG –
ON→OFF LOCAL –
SwitchtoHOLD(Startofhold-modeoperation)
The mode can be switched to HOLD (start of hold-mode operation) using contact input.
(Switch by the rising edge)
Contact status Operation Remark
OFF→ON Switch to HOLD (start of hold-mode operation) –
ON→OFF Maintains the current operation status –
Advanceofsegment(ADV)
The mode can advance from the current segment to the next segment using contact
input. (Switch by the rising edge)
Contact status Operation Remark
OFF→ON Advance from the current segment to the next segment –
ON→OFF Maintains the current operation status –
WaitON/OFFswitch(WAIT)
Wait ON/OFF in the segment switching can be switched using contact input. (Status
switch)
Contact status Operation Remark
ON Wait (switching between segments) –
OFF Wait release –
Thisfunctionisavailableonlyforsynchronizedoperation.Set"OFF"totheparameterfor
operationsexceptsynchronizedoperation.
SwitchtoHOLDforsynchronizedprogramoperation(S.HLD)
HOLDON/OFFforsynchronizedprogramoperationcanbeswitchedusingcontactinput.
(Status switch)
Contact status Operation Remark
ON
Wait (wait within a
segment interval.)
Switch by keystroke or via communication is disabled.
OFF Hold release Switch by keystroke or via communication is enabled.
Thisfunctionisavailableonlyforsynchronizedoperation.Set"OFF"totheparameterfor
operationsexceptsynchronizedoperation.
