12-5
IM 05P02C41-01EN
Contact Input/Output Functions
12
• Status switch 2 (Operation by keystroke or via communication is disabled.)
Program pattern
number
Contact status
PT.B3 PT.B2 PT.B1 PT.B0
1
OFF OFF OFF OFF
2
OFF OFF OFF ON
3
OFF OFF ON OFF
4
OFF OFF ON ON
5
OFF ON OFF OFF
6
OFF ON OFF ON
7
OFF ON ON OFF
8
OFF ON ON ON
9
ON OFF OFF OFF
10
ON OFF OFF ON
A program pattern is selected with the combination of ON and OFF of a contact input. The pattern
11 or later can be selected similarly.
*1: “1” when the contact input is turned on and “0” when turned off.
*2: Contact input is turned off when the bit of program pattern number is not assigned to the contact
input.
• BCD switch (Operation by keystroke or via communication is disabled.)
Program pattern
number
Contact status
Highorderdigit(0to3) Loworderdigit(0to9)
PT.B5 PT.B4 PT.B3 PT.B2 PT.B1 PT.B0
1
OFF OFF OFF OFF OFF ON
2
OFF OFF OFF OFF ON OFF
3
OFF OFF OFF OFF ON ON
4
OFF OFF OFF ON OFF OFF
5
OFF ON OFF ON OFF ON
6
OFF ON OFF ON ON OFF
7
OFF ON OFF ON ON ON
8
OFF ON ON OFF OFF OFF
9
OFF OFF ON OFF OFF ON
10
OFF ON OFF OFF OFF OFF
11
OFF ON OFF OFF OFF ON
12
OFF ON OFF OFF ON OFF
A program pattern is selected with the combination of ON and OFF of a contact input. The pattern
13 or later can be selected similarly.
Example: pattern 23
PT.B5:ON, PT.B4: OFF, PT.B3: OFF, PT.B2: OFF, PTB1: ON, PT.B0: ON
*1: “1” when the contact input is turned on and “0” when turned off.
*2: Contact input is turned off when the bit of program patttern number is not assigned to the
contact input.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
PT.BC
Bit changing method
of program pattern
number
PRO
0: Status switch 1
1: Status switch 2
2: BCD switch
DI.NU
12.1SettingContactInputFunction
