YOKOGAWA UP55A User Manual

12-13
IM 05P02C41-01EN
Contact Input/Output Functions
12
PVEventStatus
PV event status can be output to the contact output. (The setpoints below are I relay
numbers.)
► I relay: UTAdvanced Series Communication Interface (RS-485, Ethernet) User's Manual
Setpoint
Function
PVevent
status
PVevent
output status
4785 4801 PV event 1
4786 4802 PV event 2
4787 4803 PV event 3
4789 4805 PV event 4
4790 4806 PV event 5
4791 4807 PV event 6
4793 4809 PV event 7
4794 4810 PV event 8
• PV event status: The internal alarm status is turned on when an alarm occurs and
turned off in normal condition
• PV event output status: Contact output status when an alarm occurs (ON in alarm
condition and OFF in normal condition)
TimeEventStatus
Time event status can be output to the contact output. (The setpoints below are I relay
numbers.)
► I relay: UTAdvanced Series Communication Interface (RS-485, Ethernet) User's Manual
PVeventstatus Function
4817 Time event 1
4818 Time event 2
4819 Time event 3
4821 Time event 4
4822 Time event 5
4823 Time event 6
4825 Time event 7
4826 Time event 8
4833 Time event 9
4834 Time event 10
4835 Time event 11
4837 Time event 12
4838 Time event 13
4839 Time event 14
4841 Time event 15
4842 Time event 16
12.2SettingContactOutputFunction
